Edwards iXM Series User Manual

Remedy
1. Examine the equipment recently connected to the pump. Make sure that is
inst
alled and correctly connected.
2. If the warning does not disappear power cycle the pump.
3. If the warning re-appears aer power cycling, contact us.
Fault Event 258.63 - USB V oload
Cause Faulty equipment has just been plugged in
Remedy
1. Examine the equipment recently connected to the pump. Make sure that is
inst
alled and correctly connected.
2. If the warning does not disappear power cycle the pump.
3. If the warning re-appears aer power cycling, contact us.
8.5 Inverter warnings and alarms
The inverters used to drive the dry pump and booster can also give warnings and alarms
if problems are idened. Inverter warning and alarm codes are displayed by the PDT if
installed.
Table 38 Inverter warning and alarm status registers
Inverter warning
and alarm status
registers
Text displayed on
PDT as alert and fault
history
Descripon Recommended acon
0123456789012
0800 0000 NO_INV_PARAMS No inverter parameters set loa-
ded.
No inverter parameters
set loaded.
0000 0010 POWER_DOWN___ Supply voltage collapsed (power
o)
Check Supply Voltage
0000 0008 POWER_DOWN___ Supply voltage collapsed (power
o)
Check Supply Voltage
0040 0000 EMS_ACTIVATED EMS acvated EMS acvated
0080 0000 MISSING_PHASE Missing Phase in mains supply Missing Phase in mains
supply
0000 0200 MTR_TEMP_HIGH High Motor Temperature Check cooling
0000 0020 MTR_TEMP_HIGH High Motor Temperature Check cooling
0000 0400 INV_TEMP_HIGH High Inverter Sink Temperature Check cooling
0000 0040 INV_TEMP_HIGH High Inverter Sink Temperature Check cooling
0000 0800 INV_TEMP_HIGH High Inverter Processor Temper-
ature
Check cooling
0008 0000 INV_TEMP_HIGH High Inverter Temperature Trip Check cooling
0000 0100 MISSING_PHASE Missing Phase in mains supply Missing Phase in mains
supply
8000 0000 LOW_SPEED____ Acceleraon meout (Pump
Seized/overload)
Acceleraon meout
(Pump Seized/overload)
10/2020 - ©Edwards Limited
Page 83M56635880_D
M56635880_D - Fault nding
