USING THE E-43A 35
3 From the Home screen of the copier/printer touch panel, select Fiery. If the Fiery icon does
not display, press the button ( )on the upper right corner of the screen to switch to the
icon view.
If the system has just finished processing, wait at least five seconds after the system reaches
Idle before beginning the shutdown procedure.
NOTE: Notify the network administrator before you remove the E-43A from the network.
4 Press the Fiery tab.
5Press Restart Fiery.
6 At the next screen, select one of the following options:
• Restart Fiery Service (soft reset)—Resets the E-43A server software but does not reboot
the entire system. Network access to the E-43A is temporarily interrupted and all currently
processing jobs are aborted and may be lost. If you choose this option, you may need to
wait 1 minute or more for the server software to reset.
•
Reboot System (hard reset)—Shuts down all E-43A activity properly and then reboots.
Network access to the E-43A is temporarily interrupted and all currently processing jobs
are aborted and may be lost.
•
Shut Down—Shuts down all E-43A server software and powers off the system. You should
always select this option when you want to power off the system. Network access to the
E-43A is terminated and all currently processing jobs are aborted and may be lost.
NOTE: Use the reset button on the front of the E-43A only if the system is unresponsive to
keyboard or mouse actions.
7Press OK.
Before accessing internal components, make sure that all cables are disconnected from the
back of the E-43A.
Power synchronization
You can enable the power synchronization feature by using the switch on the printer interface
board. The default switch position is OFF.
When you enable power synchronization, the E-43A synchronizes power with the copier/
printer’s main power off/on status. If the copier/printer powers off, the E-43A receives signals
from the copier/printer through the USB cable connected to the printer interface board, and
automatically starts the shutdown process. If the E-43A receives the startup signals from the
copier/printer, the E-43A automatically powers on and begins the startup sequence.
NOTE: The USB cable may not be provided in some regions or countries. If the customer site
requires the power synchronization and the USB cable was not provided with the copier/
printer, contact your authorized support/service center.
After the power synchronization is enabled, make sure to control the E-43A power using the
copier/printer.
