REPLACING PARTS 78
7 Remove the four screws that attach the hard disk drive to the hard disk drive bracket (see
below).
FIGURE 30: Removing/replacing the hard disk drive from/in the hard disk drive bracket
8 Remove the hard disk drive from the hard disk drive bracket and place it in an antistatic bag.
Do not unscrew the screws on the hard disk drive cover. Loosening these hard disk drive
screws breaks the seal and voids the hard disk drive warranty.
Do not touch the drive with magnetic objects (such as magnetic screwdrivers), and avoid
placing magnetic-sensitive objects (such as credit cards and employee ID cards) near the hard
disk drive.
Replacement hard disk drives are not shipped with preinstalled system software. After you
install the drive, you must install the appropriate system software.
Hard disk drive
bracket
Hard disk drive
Screw (1 of 4)
