REPLACING PARTS 44
Opening the E-43A
To service internal components, open the E-43A as described in the following procedure.
• The E-43A weighs approximately 20Kg. Be careful when moving the device.
• Never lift the E-43A by grasping the top panel. The top panel does not support the weight of
the system.
AVERTISSEMENT: Ne jamais soulever le serveur d'impression par sa partie supérieure : celle-ci ne peut pas supporter le
poids du système.
AVVERTENZA: Il server di stampa non deve essere mai sollevato afferrandolo dal pannello superiore, in quanto
quest'ultimo non può sostenere il peso dell'intero sistema.
WARNUNG: Heben Sie den Druckserver nicht an der oberen Gehäuseabdeckung an. Die obere Gehäuseabdeckung ist
nicht dafür ausgelegt, das Gesamtgewicht des Systems zu tragen.
ADVERTENCIA: No levante nunca el servidor de impresión agarrándolo por el panel superior. El panel superior no
soporta el peso del sistema.
AVISO: Nunca erga o servidor de impressão pelo painel superior. O painel superior não suporta o peso do sistema.
WAARSCHUWING: Til de afdrukserver nooit op door het bovenpaneel vast te nemen. Het bovenpaneel kan het gewicht
van het systeem niet dragen.
TO OPEN THE E-43A
1 Shut down the E-43A (see page 43).
2 Remove all cables from the back of the E-43A.
3 Remove the E-43A from the furniture (see page 45).
4 Remove all panels necessary to access the component that you need to service.
For guidelines on which panels to remove, see the service procedure for the component that
you want to access.
NOTE: When removing multiple panels from the E-43A, use the following order:
• Left panel (see page 45)
• Right panel (see page 45)
• Front panel (see page 46)
• Top panel (see page 47)
NOTE: When replacing panels, reverse the order.
5 Place the E-43A on a flat surface. Attach an ESD wrist strap before handling internal parts
(see page 11).
6 Carefully position the E-43A so that it is resting on its side and the internal components are
facing up.
Place removed components on a grounded, antistatic surface.
