Table 9-1. Setting PlantWeb Alerts (Continued)
PlantWeb Alert
and (Group)
Alert Category
and (Default)
Alert Condition
and (Default)
What the Alert is
Detecting
Related Parameters and
(Default)
Guidelines for Setting
Travel Sensor
(Sensors)
User Config.
(Failed)
Travel Sensor
(Enabled)
The parameter TVL_COUNT
is greater than TVL_FAC_HI
or less than TVL_FAC_LO.
Self Test Shutdown (No)
Shutdown Recovery (Auto)
Double Acting Actuators—
Enable the alert
and
configure it to report in the
Failed Alert Category. Self
Test Shutdown is generally
not enabled.
Single Acting Actuators—
If Travel / Pressure Control
is configured as Travel with
Pressure Fallback: enable
the alert and configure it to
report in the Maintenance
Alert Category. Do not
enable Self Test Shutdown.
If Travel / Pressure Control
is configured as Pressure:
Do not enable the alert or
the Self Test Shutdown.
If Travel / Pressure Control
is configured as Travel:
Enable the alert
and
configure it to report in the
Failed Alert Category. Self
Test Shutdown is generally
not enabled.
Output Press
Sensor
(Sensors)
User Config.
(Maintenance)
Port A Pressure
Sensor (Enabled)
The pressure sensor reading
is outside the functional range
of the sensor.
Self Test Shutdown (No)
Shutdown Recovery (Auto)
If Travel / Pressure Control
is configured as Pressure:
enable the alert
and
configure it to report in the
Failed Alert Category.
Enable the Self Test
Shutdown.
For all other Travel /
Pressure Control selections,
enable the alert
to report in
the Maintenance Alert
Category and do not enable
the Self Test Shutdown.
Port B Pressure
Sensor (Enabled)
None Use default settings
Supply Press
Sensor
(Sensors)
User Config.
(Advisory)
Supply Press
Sensor (Enabled)
The pressure sensor reading
is outside the functional range
of the sensor.
None Use default settings
Temperature
Sensor
(Sensors)
User Config.
(Advisory)
Temperature Sensor
(Enabled)
The temperature sensor
reading is outside the
functional range of the sensor.
None Use default settings
