Viewing Device Information
March 2006
7-3
 Device Revision
Device Revision (DEV_REV [12]) identifies the device
revision number. It is used by the host system to
locate the DD file for the device.
 DD Revision
DD Revision (DD_REV [13]) identifies the minimum
revision of the device description (DD) that is
compatible with the Device Revision (DEV_REV [12])
of the instrument.
 ITK Version
ITK Version (ITK_VER [41]) identifies the major
version of the Interoperability Tester used by the
Fieldbus Foundation in certifying the device as
interoperable. This device revision meets the
requirements of version 4.
 Features
Features (FEATURES [17]) shows the supported
resource block options.
 Software Rev All
Software Revision All (SOFTWARE_REV_ALL [47.6])
shows all device software revisions currently in
operation.
 Stby Software Rev All
Standby Software Revision All
(STBY_SOFTWARE_REV_ALL [55.6]) shows all
device software revisions currently in standby.
Options
(RB > Display > Options)
The following parameters are contained in the the
Options menu of the resource block.
 Diag Options
Diagnostic Options (DIAG_OPTIONS [45]) shows the
diagnostic options available in the instrument.
 Function Block Options
Function Block Options (FB_OPTIONS [44]) shows
which function blocks are available in the instrument.
 Misc Options
Miscellaneous Options (MISC_OPTIONS [46])
indicates which miscellaneous licensing options are
enabled.
 Feature Selection
Feature Selection (FEATURE_SEL [18]) indicates
which device features have been selected.
Resource Status
(RB > Display > Resource Status)
The following parameters are contained in the the
Resource Status menu of the resource block.
 Block Error
Block Error (BLOCK_ERR [6]) indicates an error
status associated with hardware or software for the
resource block.
Table 7-1 lists conditions reported in the BLOCK_ERR
[6] parameter. Conditions in italics are not applicable
for the resource block and are provided only for your
reference.
Table 7-1. Resource Block BLOCK_ERR Conditions
Condition
Number
Condition Name and Description
0 Other - Set if a device initialization error occured.
1
Block Configuration Error - Set if FEATURE_SEL,
CYCLE_SEL, or CYCLE_TYPE is set incorrectly.
2 Link Configuration Error - N/A
3
Simulate Active - Indicates that the simulation jumper is
in place on the aux terminals. This is not an indication
that the I/O blocks are using simulation data. See AO
block paramter SIMULATE [10] and DO block parameter
SIMULATE_D [10].
4 Local Override - N/A
5 Device Fault State - N/A
6
Device Needs Maintenance Soon - Indicates a
Maintenance PlantWeb Alert condition is active.
7 Input failure/process variable had Bad status - N/A
8 Output failure - N/A
9
Memory failure - Indicates a pending Flash or NVM
failure.
10
Lost Static Data - Indicates failure of the memory
containing static parameters
11
Lost NV Data - Indicates failure of the memory containing
non-volatile parameters.
12 Readback Check Failed - NA
13
Device Needs Maintenance Now - Indicates a Failed
PlantWeb Alert condition is active.
14
Power Up - Indicates the device has been powered up
and the Resource Block is not
running normally.
15
Out of Service (MSB) - The resource block actual mode
is Out of Service.
7
