Epiroc ER-L Series User Manual

Safety and operating instructions
22 © Anbaufräsen PC GmbH | 3390 5221 01 | 2020-09-07
Original Instructions
3.10 Tools for round attack picks
Set of tools for round attack pick
Type A B C D E F
ER 100 L x x x
ER 250 L x x x
ER 400 L x x x
ER 450 L x x x x
ER 600 L x x x x
ERL 700 x x x x
ERL 1100 x x x
ER 1500 L x x x
ER 2000 L x x x
A. Knock out tool
B. Knock out tool for stuck picks (optional)
C. Mounting tool for knock on retainer
D. Dismantling tool for knock on retainer
E. Dismantling tool for Quick snap retainer
F. Puller for retainer sleeve picks

Epiroc ER-L Series Specifications

General

Brand	Epiroc
Model	ER-L Series
Category	Cutter
Language	English
