Safety and operating instructions
24 © Anbaufräsen PC GmbH | 3390 5221 01 | 2020-09-07
Original Instructions
4.2 Transport using a forklift
truck
Always transport the drum cutter whilst secured to the
assembly stand.
WARNING Hydraulic attachment tipping over
The hydraulic attachment tipping off the fork of the forklift
truck or the pallet may cause serious injury.
u Place the hydraulic attachment on a pallet.
u Strap the hydraulic attachment to the pallet using
suitable strapping, as shown in the illustration below.
u Move the fork of the forklift truck under the pallet so
that the centre of gravity is between the prongs.
n
Move the forks of the forklift truck under the assembly
stand so that the hydraulic attachment cannot tip
over.
n
Slowly lift the assembly stand with the hydraulic at-
tachment.
n
Transport the assembly stand with the hydraulic at-
tachment to the location provided for.
4.3 Transport using a truck
Always transport the drum cutter whilst secured to the
assembly stand.
WARNING Hydraulic attachment tipping over /
slipping
The hydraulic attachment slipping or tipping over and
falling from the loading area of a lorry may cause serious
injury.
u Place the hydraulic attachment on a pallet.
u Strap the hydraulic attachment to the pallet using
suitable strapping (see illustration in chapter Trans-
port using a forklift truck).
u Place the pallet with the hydraulic attachment on an
anti-slip mat.
u Secure the hydraulic attachment to the loading area
with ropes or chains; use any available transport
lugs.
n
Secure the hydraulic attachment on the assembly
stand and the loading surface as shown in the follow-
ing illustration.
n
Observe all the applicable national/regional regula-
tions on securing loads.
