12 Technical specifications
Type ER 100-2L ER 100-3L ER 100-4L
Carrier weight class
1
3 - 7 t (6600 - 15430 lbs)
Service weight
2
250 kg (551 lbs)
Weight without adapter
3
210 kg (463 lbs)
Dimensions
Total length
Length of cutter drum
Diameter of cutter drum
810 mm (31.89 in.)
310 mm (12.21 in.)
370 mm (14.57 in.)
Nominal power 30 kW (40 hp)
Oil flow rate idling, max. 90 l/min (23.8 gal (US)/min)
Oil flow rate, recommended at 200bar (2900psi) 52 l/min
(13.7 gal (US)/min)
57 l/min
(15.1 gal (US)/min)
62 l/min
(13.4 gal (US)/min)
Operating pressure, max. 350 bar (5075 psi)
Rotational speed, recommended 110 rpm
Pick speed 2.1 m/s (6.9 fps)
Number of picks 32
Pick shaft diameter 20 mm (0.79 in.)
Maximum cutting force at 350 bar (5075 psi) 14.0 kN
(3147 lbf)
15.7 kN
(3530 lbf)
16.9 kN
(3799 lbf)
Maximum torque at 350 bar (5075 psi) 2600 Nm
(1918 ft lbs)
2900 Nm
(2139 ft lbs)
3120 Nm
(2301 ft lbs)
Maximum rock hardness 35 MPa (5076 psi)
Gear oil volume 0.25 l (0.07 gal)
Oil volume hydraulic motor 1 l (0.26 gal)
Hydraulic connections (Drum cutter)
Pressure / tank line
Leakage oil line
M24x1.5
M22x1.5
Hose lines (inside diameter)
Pressure / tank line
Leakage oil line
12 mm (0.47 in.)
12 mm (0.47 in.)
1
Weight applies to standard carriers only. Any variations must be agreed with AnbaufräsenPCGmbH and / or the car-
rier manufacturer.
2
Drum cutter including adapter plate of medium size. Please note that the working weight can be considerably higher,
depending on the adapter plate.
3
Drum cutter including rotatable upper part. Accessory parts such as the adapter plate are not included.
