Epiroc ER-L Series User Manual

Safety and operating instructions
© Anbaufräsen PC GmbH | 3390 5221 01 | 2020-09-07
Original Instructions
79
12.1 Technical specifications ADU
Type ADU 100 ADU 250 ADU 450 ADU 600
Carrier weight class
1
3 - 7 t
(6614 - 15432 lbs)
8 - 15 t
(17637 - 33069 lbs)
8 - 17 t
(17637 - 37479 lbs)
14 - 22 t
(30865 - 48502 lbs)
Service weight
2
280 kg
(617 lbs)
420 kg
(926 lbs)
445 kg
(981 lbs)
750 kg
(1654 lbs)
Product weight 240 kg
(529 lbs)
350 kg
(772 lbs)
370 kg
(816 lbs)
670 kg
(1477 lbs)
Nominal power 30 kW
(40 hp)
45 kW
(60 hp)
65 kW
(87 hp)
65 kW
(87 hp)
Dimensions
A
B
H
(hex)
900 mm
(35.43 in.)
300 mm
(11.81 in.)
80 mm
(3.15 in.)
810 mm
(31.89 in.)
350 mm
(13.78 in.)
80 mm
(3.15 in.)
810 mm
(31.89 in.)
350 mm
(13.78 in.)
80 mm
(3.15 in.)
1260 mm
(49.61 in.)
350 mm
(13.78 in.)
80/120/160 mm
(3.15/4.72/6.30 in.)
Rotational speed 50 - 110 rpm 40 - 80 rpm 40 - 80 rpm 40 - 80 rpm
Oil flow, optimal
3
30 - 60 l/min
(7.93 - 15.85 gal
(US)/min)
40 - 75 l/min
(10.57 - 19.81 gal
(US)/min)
75 - 150 l/min
(19.81 - 39.63 gal
(US)/min)
75 - 150 l/min
(19.81 - 39.63 gal
(US)/min)
Torque, max.
4
3120 Nm
(2301 ft lbs)
5200 Nm
(3835 ft lbs)
10400 Nm
(7671 ft lbs)
10400 Nm
(7671 ft lbs)
Oil flow, max.
5
90 l/min
(23.76 gal (US)/min)
85 l/min
(22.46 gal (US)/min)
170 l/min
(44.90 gal (US)/min)
170 l/min
(44.90 gal (US)/min)
Operating pressure, max. 350 bar (5075 psi)
1
Weight applies to standard carriers only. Any variations must be agreed with AnbaufräsenPCGmbH and / or the car-
rier manufacturer.
2
Attachment with average-sized adapter plate.
3
 at 200 bar (2900 psi)
4
 at 350 bar (5075 psi)
5
 at 10 bar (145 psi)
A
H
B
