Fronius MagicWave 3000 User Manual

Mains connection
1)
Z
max
on PCC
3)
= 97 mOhm
Primary continuous power (100% D.C.
2)
)
3 x 400 - 460 V
3 x 200 - 240 V
1 x 200 - 240 V
5.9 kVA
5.0 kVA
4.3 kVA
Cos phi 0.99
Welding current range (3-phase)
TIG 3 - 300 A
Electrode 10 - 300 A
Welding current range (single phase)
TIG 3 - 220 A
Electrode 10 - 180 A
Welding current at 3 x 400 - 460 V
10 min/40 °C (104 °F) 45% D.C.
2)
300 A
10 min/40 °C (104 °F) 50% D.C.
2)
-
10 min/40 °C (104 °F) 100% D.C.
2)
240 A
Welding current at 3 x 200 - 240 V
10 min/40 °C (104 °F) 35% D.C.
2)
300 A
10 min/40 °C (104 °F) 40% D.C.
2)
-
10 min/40 °C (104 °F) 100% D.C.
2)
210 A
Welding current at 1 x 200 - 240 V
10 min/40 °C (104 °F) 50% D.C.
2)
-
10 min/40 °C (104 °F) 55% D.C.
2)
220 A
10 min/40 °C (104 °F) 100% D.C.
2)
190 A
Open circuit voltage 85 V
Working voltage
TIG 10.1 - 22.0 V
Electrode 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23
Type of cooling AF
Insulation class B
EMC device class
(in accordance with EN/IEC 60974-10)
A
Dimensions L/W/H (with handle) 560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
Weight 25.9 kg
57.10 lb.
Mark of conformity S, CE
212
