1 Before Using the Device
18
Control Panel
No. Component Function
1 Touch screen Displays messages required for operation, and buttons for various features.
You can directly touch the touch screen to instruct operations and set
features.
2 Power button Press this button to turn the device on or off. You can use the button to
wake the device or put it to the Power Saver mode. The button flashes
slowly when the device is in the Power Saver mode.
3 Home button Press this button to display the Home screen.
4 NFC area Hold your NFC-enabled mobile device near this area. The NFC feature must
be enabled on the device to communicate with each other.
For details, refer to "Print via NFC" (P.84).
5 Data LED Blinks when the device is sending or receiving data to or from a client.
This indicator lights up when data is stored in the device memory, or when
faxes are stored in a folder.
6 USB memory slot Insert a USB 2.0 memory device directly here.
7 Status LED Briefly glows blue when an operation is accepted or when a process is
completed. The LED flashes amber if a system error or a problem with the
device occurs, including paper jams and running out of paper or toner.
To Next Page
