GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
9-20 Section 9-13 - Probe
Section 9-13Probe
Table 9-11 Probes for LOGIQ P3
Item Part Name Part Number Description Quantity
1201 4C 5123455 Probe (Center Frequency: 3.2MHz) 1
1202 E8C 2294641 Probe (Center Frequency: 6.5MHz) 1
1203 8C 2348094 Probe (Center Frequency: 6.5MHz) 1
1204 5CS 5143934 Probe (Center Frequency: 5.6MHz) 1
1205 8L 5140738 Probe (Center Frequency: 6.2MHz) 1
1206 3S 2323337 Probe (Center Frequency: 2.0MHz) 1
1207 11L 5171885 Probe (Center Frequency: 7.5MHz) 1
1208 E8CS 47236865 Probe (Center Frequency: 6.5MHz) 1
1209 T739 2259246 Probe (Center Frequency: 6.4MHz) 1
Along with the above Probes, LOGIQ P3 BT10 include the following Probes:
1210 3.8CA 5334810 Probe (Center Frequency: 3.75MHz±10%) 1
1211 6S 47236867 Probe (Center Frequency: 6.0MHz) 1
1212 7.5LA 5334811 Probe (Center Frequency: 7.5MHz±10%) 1
