Revision E
MAC
5500 resting ECG anal
ysis system
4-29
2020299-020
T
rou
bleshooting:
CPU PCB Input/Output Signals
17
G4
18
G5 (MSB)
19
Ground
20
B0 (LSB)
21
B1
22
B2
23
B3
24
B4
25
B5 (MSB)
26
Ground
27
Data Enable
28
3V Power
29
3V Power
30
NC
31
NC
Power Supply/Motor, J11
