Revision E MAC 5500 resting ECG analysis system 5-25
2020299-020
Maintenance: Functional Checkout Procedures
Functional Checkout Procedures
This checkout procedure applies to all MAC 5500 systems.
NOTE
The FRU checkout procedure for any li
sted FRU also applies to its internal
PCBs and components. Perform the applicable product or product configuration
dependant procedures when an asterisk * is listed.
Table 3. FRU Repairs
FRU Description Tools Visual Inspection Checkout Procedure(s)
CAM 14 5 1,2,7 1,2,3
CAM 14 I/F Cable 5 1,2 1,2,3
Battery Pack 1,5 5 1,3,11
Shock Cylinder 1,2,4,5 9 1,3
Motherboard 1,2,3,4,5 3,5,9,10 1,2,3,4,13,20
*5 through 9
Roller Assy 1,2,4,5 9 1,2,3,15
Writer Assy 1,2,4,5 9 1,2,3,15
Display Assy 1,2,4,5 3,7,9 1,2,3,12
Keyboard Assy 1,2,4,5 3,9
1,2,3,14
Power Supply Assy 1,2,3,4,5 9,10 1,2,3
Plastics 1,2,3,4,5 7,9,10 1,3, *20
*Bottom Plastic
Replacement Only
Trolley or Casters 2,5 6,9 10
AC Power Cord 3,5 4 1,3
Non-Listed FRUs 1,2,4,5 9,10 1,2,3,4,20
*5 through 9
Table 4. Option Repairs
FRU / Option Tools Visual Inspection Checkout Procedure(s)
External Modem 1,2,5 9 1,3,5,17
Internal Modem (Comm PCB) 1,2,4,5 9 1,3,5,17
SD Card Storage 1,5,6 N/A 1,3,4,18
