4-30
MAC
5500 resting ECG anal
ysis system
Revision E
2020299-020
T
rou
bleshooting:
CPU PCB Input/Output Signals
Thermal Printer, J12
Pin No.
Signal
1
Thermal Printer Power
2
Thermal Printer Power
3
Thermal Printer Power
4
Thermal Printer Power
5
Thermal Printer Power
6
Thermal Printer Power
7
Thermal Printer Power
8
Ground
9
Ground
10
Ground
11
Ground
12
Ground
13
Ground
14
Ground
15
Cue Sense
16
NC
17
5V Main Power
18
Ground
19
Data Strobe
20
Data Strobe
21
Data Strobe
22
Data Strobe
23
Data Load
24
Data Clock
25
Print Head Temperature
26
Pixel Data
101
103
