Revision E MAC 5500 resting ECG analysis system B-5
2020299-020
Appendix B – Technical Specifications: Technical Specifications
Hi-Res and PHi-Res Signal-Averaged Electrocardiography
Item Description
Frequency Response/Input -3 dB @ 0.01 and 250 Hz
Frequency Response/Output
Upper Limit
Lower Limit
250 Hz
0.01, 25, 40 or 80 Hz
Sensitivities
Raw Data and Template
Average Beat
Filtered Signals and Vector
Magnitude
20 mm/mV
20 mm/mV and 50 mm/mV
1 mm/µV
Analysis Sampling Rate 1000 samples per second per channel
Digital Sampling Rate 4000 samples per second per channel
High/Low Pass Filters Spectral filter using Fast Fourier Transform (FFT)
ADC Resolution 1.22 µV/LSB
Analysis Resolution 0.1525 µV/LSB
Physical
1
Item Description
Height 9.4 cm (3.7 in) with display closed
Width 38.1 cm (15.0 in)
Depth 35.1 cm (13.8 in)
Weight 6.8 kg (15 lb) without paper
1. without trolley
Environmental
Item Description
Operating Conditions
Temperature
Relative Humidity
Atmosphere Pressure
10° C to 40° C (50° F to 104° F)
1
20% to 95% RH noncondensing
700 to 1060 hPa
