Revision E
MAC
5500 resting ECG anal
ysis system
4-25
2020299-020
T
roubleshooting:
Input and Output Connectors
COM2 Pins (J5)
Analog Pins (J6)
Table 4. COM2 Pins (J5)
Pin
Name
1
RTS
2
CTS
3
TxD
4
Ground
5
RxD
6
DTR
7
+12V
8
DSR
6
3
1
8
5
4
2
7
67A
Table 5. Acquisition Module Connector (J6)
Pin
Name
1
+12V
2
DC Output 1
3
TTL Trigger Output
4
Ground
5
Ground
6
DC Output 2
7
DC Input 1
8
ECG Output
9
DC Input 2
6
9
5
1
68A
96
98
