GE MAC 800 Service Manual

Maintenance
2031504-159D MAC™ 800 4-27
Electrical Safety Checks
11. Verify the battery test was successful.
See “Battery Test” on page 3-11 for more information.
12. Verify the LAN test was successful.
See “LAN Test” on page 3-14 for more information.
13. Verify the modem test was successful.
See “Modem Test” on page 3-15 for more information.
14. Verify the current leakage test results meet the requirements.
Perform electrical safety checks when indicated. All indicated electrical safety
checks require a pass/fail indication for the steps performed. Record the
measurement values in your debrief.
Electrical Safety Checks
Step
Condition
1
UUT - ON
2
Result Leakage Current Limits
Earth Leakage Current
1 Forward Polarity NC
______

Pass/Fail
500

2 Neutral Open, Forward Polarity SFC
______

Pass/Fail
1,000

3 Neutral Open, Reverse Polarity SFC
______

Pass/Fail
1,000

4 Reverse Polarity NC
______

Pass/Fail
500

Enclosure Leakage Current
1 Forward Polarity NC
______

Pass/Fail
100

2 Neutral Open, Forward Polarity SFC
______

Pass/Fail
500

3 Ground Open, Forward Polarity SFC
______

Pass/Fail
500

4 Ground Open, Reverse Polarity SFC
______

Pass/Fail
500

5 Neutral Open, Reverse Polarity SFC
______

Pass/Fail
500

6 Reverse Polarity NC
______

Pass/Fail
100

Patient Leakage Current To Ground
1 Forward Polarity NC
______

Pass/Fail
10

2 Neutral Open, Forward Polarity SFC
______

Pass/Fail
50

3 Ground Open, Forward Polarity SFC
______

Pass/Fail
50

4 Ground Open, Reverse Polarity SFC
______

Pass/Fail
50

