Parts Lists
2031504-159D MAC™ 800 5-13
FRU Top Cover Assembly, PN 2039939-001
The following table summarizes the items in the FRU Top Cover
Assembly. Item numbers correspond to the item numbers in the MAC
800 Upper Level Assembly Diagrams beginning on page 5-3.
FRU Printer Assembly, PN 2039941-001
The following table summarizes the items in the FRU Printer Assembly.
Item numbers correspond to the item numbers in the “MAC 800 Upper
Level Assembly Diagrams” on page 5-3.
FRU Top Cover Assembly, PN 2039939-001
Item Description Qty
2 LCD POLY FOAM 1
3 LCD LENS 1
4 PRINTER BUTTON 1
5 TOP COVER 1
6 NAMEPLATE 15MM GE LOGO 1
FRU Printer Assembly, PN 2039941-001
Item Description Qty
9 PRINTER DOOR 1
10 THERMAL PRINTER HEAD-MAC800 1
11 M2X6 MACHINE SCREW PHILIPS PAN 3
12 PRINTER HOLDER 1
