2031504-159D MAC™ 800 5-15
FRU Bottom Cover Assembly, PN 2039943-001
The following table summarizes the items in the FRU Bottom Cover
Assembly. Item numbers correspond to the item numbers in the “MAC
800 Upper Level Assembly Diagrams” on page 5-3.
FRU Bottom Cover Assembly, PN 2039943-001
Item Description Qty
1 M3X8 MACHINE SCREW PHILIPS PAN NI 17
21 FLAT SCREW M3X12 2
22 CRIMP RING .217 2
24 M4X16 MACHINE SCREW PHILIPS PAN NI 6
25 FUSE 2.0A QUI-BLO 250V 5X20MM 2
26 HEXAGON SCREW1 4
27 HEXAGON SCREW2 4
28 SHIELD PLATE 1
29 CLIP-ON FOR SHIELD COVER 1
31 CABLE FOR BATTERY 1
32 PRINTER MOUNTING BASE 1
33 PRINTER GROUND POLE 1
34 PAPER TRAY SHEET 1
35 PAPER LIFTING TAPE 1
36 PRINTER SPRING 1
37 FOOTPAD1 2
38 FOOTPAD2 1
39 FOOTPAD3 1
43 HINGE LEFT 1
44 HINGE RIGHT 1
45 ST2.9X9.5 SELF TAPPING SCREW NI 6
46 BOTTOM COVER 1
47 HANDLE BOTTOM 1
48 HANDLE TOP 1
49 M3X10 MACHINE SCREW PHILIPS PAN NI 2
