GE MAC 800 Service Manual

5-14 MAC™ 800 2031504-159D
Parts Lists
FRU Mainboard Assembly, PN 2039942-001
The following table summarizes the items in the FRU Mainboard
Assembly. Item numbers correspond to the item numbers in the “MAC
800 Upper Level Assembly Diagrams” on page 5-3.
FRU Power Supply Assembly, PN 2040052-001
The following table summarizes the items in the FRU Power Supply
Assembly. Item numbers correspond to the item numbers in the “MAC
800 Upper Level Assembly Diagrams” on page 5-3.
FRU Mainboard Assembly, PN 2039942-001
Item Description Qty
1 M3X8 MACHINE SCREW PHILIPS PAN NI 7
13 PCB MAC800 MAINBOARD 1
14 REAR PANEL 1
15 ACQ COVER1 1
16 ACQ COVER2 1
17 PATIENT CABLE CONNECTOR HOLDER 1
18 AN00388 4-40x3/8 SCREW NI 2
19 SD CARD HOUSE 1
FRU Power Supply Assembly, PN 2040052-001
Item Description Qty
20 60W 12V OUTPUT AC-DC MODULE BIG HEATSINK 1
30 CABLE FOR MAIN BOARD 1
