gefran SIEIDrive AVy Series User Manual

QS
19
—————— Quick Start up ——————
1.6. LIST OF JUMPERS AND DIP-SWITCH
Designation Function Factory setting
S5 - S6 Terminating resistor for the serial interface RS485 ON (*)
ON= Termination resistor IN
OFF= No termination resistor
S8
Adaptation to the input signal of analog input 1 (terminals 1 and 2)
OFF
ON=0...20 mA / 4...20 mA
OFF=0...10V/-10...+10 V
S9
Adaptation to the input signal of analog input 2 (terminals 3 and 4)
OFF
ON=0...20 mA / 4...20 mA
OFF=0...10V/-10...+10 V
S10
Adaptation to the input signal of analog input 3 (terminals 5 and 6)
OFF
ON=0...20 mA / 4...20 mA
OFF=0...10V/-10...+10 V
S11 - S12 - S13 Encoder setting ( jumpers on kit EAM_1618 supplied with the drive) OFF
S14 - S15 - S16 ON=Sinusoidal SE
OFF=Digital DE
S17 Monitoring of the C-channel of the digital encoder OFF
ON=C-Channel monitored
OFF=C-Channel not monitored (required for single-ended channels)
S18 - S19 Encoder setting B
S20 - S21 Pos. B= reserved
Pos. A= reserved
S22 - S23 Analog input 3 enabling (alternative with SESC encoder) B
Pos. A= reserved
Pos. B=analog input 3 enabled
Pos. OFF= resolver
S26 - S27 Reserved ON
S28
Encoder Internal power supply selection
ON/ON=+5V
OFF/OFF=+8V
ON/ON
S29 Internal use A
S30
Second encoder qualifier input
A=from EXP-… board
B=from digital input "3" on RV33-4
A
Jumper to disconnect 0V (+24V power supply) from ground ON
ON = 0V connected to ground (hard-wire)
OFF = 0V disconnected from ground
Jumper to disconnect 0V (regulation board) from ground ON
ON = 0V connected to ground (hard-wire)
OFF = 0V disconnected from ground
S36 Internal use not mounted
S37 Internal use not mounted
S38-S39 Internal use ON
Power supply for the serial interface RS485 OFF
ON = Internal power supply (from pins XS.5 / XS.9)
OFF = External power supply (to pins XS.5 / XS.9)
Ay4060
(*)
on multidrop connection the jumper must be ON only for the last drop of a serial line
(**)
see chapter 5.4
S40-S41
(**)
S34
S35

gefran SIEIDrive AVy Series Specifications

General

Category	Controller
Series	AVy
Frequency	50/60 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure Rating	IP20
Communication Interface	CANopen, Ethernet

Summary

Vector AC Drives

Quick Start Up Guide

Provides essential steps for initial setup and operation of the Vector AC Drives.

Specification and Installation

Details technical specifications and installation guidelines for the Vector AC Drives.

0. SAFETY PRECAUTIONS - PRECAUTIONS DE SECURITÉ

General Safety Warnings

Highlights essential safety information and precautions before operating the drive.

1. QUICK START UP GUIDE

1.1. Functional Connection Diagram

Illustrates the basic functional connection diagram for the drive system.

1.3. Control Terminals

Details the designation, function, and specifications of the drive's control terminals.

1.4. Power Terminals

Describes the power terminal connections and cable cross-section requirements.

1.7. Keyboard Operation

Describes the keypad layout, LEDs, buttons, and navigation within menus.

1.8. Pre Power Checks

Outlines essential checks to perform before powering on the drive.

1.9. Quick Tuning

Guides through the process of quickly tuning the drive for motor operation.

1.12 Troubleshooting

Offers solutions for common issues and error messages encountered with the drive.

3. INSPECTION PROCEDURE, COMPONENT IDENTIFICATION AND STANDARD SPECIFICATION

Upon Delivery Inspection Procedures

Details the steps for inspecting the drive upon delivery.

Nameplate

Describes how to check the data on the inverter's identification and revision level nameplates.

Standard Specifications

Lists the standard specifications including environmental conditions and connections.

4. INSTALLATION GUIDELINES

Mechanical Specification

Heat Dissipation and Cooling

Mounting Clearance

Motors and Encoders

5. WIRING PROCEDURE

Power Section

Regulation Section

Standard Connection Diagram

Circuit Protection

Braking Units

Explains the operation, connection, and calculation for braking units and resistors.

AVy Power Dip Ride Through Data and Restart Setup

7. BLOCK DIAGRAM

Speed Reference generation

Speed / Torque regulator

Illustrates the closed-loop control structure for speed and torque regulation.

Ramp reference Block

Speed regulator

Motor control

Details the motor control logic including voltage, flux, and current regulators.

Motor parameters

Sensorless Parameters

PID function

Start and Stop management

Alarm mapping

Provides a mapping of alarm codes to their possible causes and actions.

8. PARAMETERS LIST
