AVy - HGB
Ch.4 58
Table 4.4.2.2: Encoders setting via S11...S23 jumpers
Encoder / Jumpers setting S11 S12 S13 S14 S15 S16 S17 S18 S19 S20 S21 S22 S23
DE OFF OFF OFF OFF OFF OFF ON (*)
------
SE ON ON ON ON ON ON
- ------
ai3150
The jumper S17 selects the inhibition or the enabling of the channel C pulses reading. It has to be correctly
selected in order to detect appropriately the encoder loss alarm.
S17 ON : channel C (index) reading=ON
S17 OFF: channel C (index) reading=OFF
(*) If the encoder is not provided of the zero channel : S17=OFF
Table 4.4.2.3: Encoders connections
123456789101112131415
B- +8V C+ C- A+ A- 0V B+ +5V E+ E- F+ F- G+ G-
DE 8 pole
l lllllll
SE 8 pole
l lllllll
DE 8 pole
lllllll l
SE 8 pole
lllllll l
ai3160
Internal +8V Encoder Power Supply
XE CONNECTOR PIN
Encoder type
Shielded
cable
Internal +5V Encoder Power Supply
To Next Page
