gefran SIEIDrive AVy Series User Manual

AVy - HGB
Ch.5 74
5.5. STANDARD CONNECTION DIAGRAM
5.5.1. AVy Connections
Figure 5.5.1.1:Control sequencing
EMERGENCY-OFF
EMERGENCY-OFF
K0
K0
S11
Off
S12
Stop
S2
ON / Start
ON / OFF
Start / Stop
K2
K2T
K2T
K2
G1
80
82
ok
t =1s
K2
K1M
K1M
Mains contactor
L01
L00
Note: OK relay must be configured as “Drive healty” for this circuit (Factory configuration)
NOTE: The connection diagram reported in the picture 5.5.1.1 (Control sequencing) is valid
only when the configuration of the sequency alarm Enable seq err is set as Ignore.
