Introduction | Accessories: HEIDENHAIN 3-D touch probes and electronic handwheels
2
HEIDENHAIN | TNC 640 | Conversational Programming User's Manual | 10/2017
129
HR electronic handwheels
Electronic handwheels facilitate moving the axis slides precisely
by hand. A wide range of traverses per handwheel revolution is
available. Apart from the HR 130 and HR 150 integral handwheels,
HEIDENHAIN also offers the HR 510, HR 520 and HR 550FS
portable handwheels.
Further information: "Traverse with electronic handwheels",
page 721
Several electronic handwheels can also be connected
simultaneously and used alternatively on controls with
the (HSCI: HEIDENHAIN Serial Controller Interface)
serial interface for control components.
Configuration is performed via the machine tool builder.

HEIDENHAIN TNC 640 Specifications

General

Control Type	CNC
Axes	Up to 18 axes
Interfaces	Ethernet, USB, RS-232
Spindle Control	Yes
PLC	Integrated
Storage	SSD
Programming Languages	DIN/ISO
Safety Features	safety functions according to EN ISO 13849-1
Dimensions	Varies based on configuration
Weight	Varies based on configuration
Operating System	Windows
