First Steps with the TNC 640 | Graphically testing the first part
1
82
HEIDENHAIN | TNC 640 | Conversational Programming User's Manual | 10/2017
Choosing the program you want to test
Press the PGM MGT key
The control opens the file manager.
Press the LAST FILES soft key
The control opens a pop-up window with the
most recently selected files.
Use the arrow keys to select the program that
you want to test. Load with the ENT key
Further information on this topic
Program number
Further information: "Working with the file manager",
page 178
Selecting the screen layout and the view
Press the key for selecting the screen layout
The control displays all available alternatives in
the soft-key row.
Press the PROGRAM + GRAPHICS soft key
In the left half of the screen the control shows
the program; in the right half it shows the
workpiece blank.
The control features the following views:
Soft keys Function
Volume view
Volume view and tool paths
Tool paths
Further information on this topic
Graphic functions
Further information: "Graphics ", page 804
Performing a test run
Further information: "Test run", page 818
