Fundamentals, File Management | Working with the file manager
4
HEIDENHAIN | TNC 640 | Conversational Programming User's Manual | 10/2017
199
Additional tools for ITCs
The following additional tools allow you to apply various settings for
the touch screens on connected ITCs.
ITCs are industrial PCs without their own memory media, and
therefore they do not have their own operating system. This feature
is what makes ITCs different from IPCs.
ITCs are frequently used with large machinery, e.g. as a clone of
the actual control system.
Refer to your machine manual.
The machine manufacturer defines and configures the
display and function of the connected ITCs and IPCs.
Additional tool Application
ITC Calibration
4-point calibration
ITC Gestures
Configuration of gesture control
ITC touchscreen
configuration
Selection of touch sensitivity
The additional tools for the ITCs are only provided by the
control in the taskbar with connected ITCs.
ITC Calibration
Using the additional tool ITC Calibration, you align the position for
the mouse cursor displayed with the actual movement position of
your finger.
Calibration using the additional ITC Calibration tool is
recommended in the following cases:
After replacing the touchscreen
When changing the touch screen position (parallel axis error due
to amended viewing angle)
Calibration involves the following steps:
Start the tool in control using the task bar
The ITC opens the calibration screen with four touch points in
the corners of the screen
Touch the four touch points shown one after the other
The ITC closes the calibration screen once calibration has been
successfully completed
ITC Gestures
Using the additional ITC Gestures tool, the machine manufacturer
configures the gesture control on the touch screen.
Refer to your machine manual.
This function may only be used with the permission of
your machine manufacturer.
