HEIDENHAIN TNC 640 User Manual

Programming Aids | Programming graphics
5
222
HEIDENHAIN | TNC 640 | Conversational Programming User's Manual | 10/2017
Block number display ON/OFF
Shift the soft-key row
To show block numbers: Set the
BLOCK NO. SHOW OMIT soft key to SHOW
To hide block numbers: Set the
BLOCK NO. SHOW OMIT soft key to OMIT
Erasing the graphic
Shift the soft-key row
Erase the graphics: Press the CLEAR GRAPHICS
soft key
Showing grid lines
Shift the soft-key row
Show grid lines: Press the Show grid lines soft
key

HEIDENHAIN TNC 640 Specifications

General

Control Type	CNC
Axes	Up to 18 axes
Interfaces	Ethernet, USB, RS-232
Spindle Control	Yes
PLC	Integrated
Storage	SSD
Programming Languages	DIN/ISO
Safety Features	safety functions according to EN ISO 13849-1
Dimensions	Varies based on configuration
Weight	Varies based on configuration
Operating System	Windows
