DS-7700NI-SP/9000/9600 Series HDVR/NVR User’s Manual
84
Notify Surveillance Center: DVR will notify surveillance center if exception is detected.
Send Email: DVR will send an email out to the designated recipients if exception is
detected.
Trigger Alarm Output: DVR will trigger alarm output if exception is detected. Selecting
this option will enable the Alarm Output list, where the output to trigger can be selected.
8. Select the Apply button to save the exception settings and select to return to the previous
menu. Selecting without clicking Apply will quit out of the menu without saving settings.
Configuring E-mail Settings
If you would like to have the DVR send out e-mails when certain events are detected or exceptions have
been triggered, you must first setup the e-mail settings.
To setup e-mail settings:
1. Enter the Email Configuration menu by going to Menu > System Configuration > Network.
2. Select the Email tab, as shown in Figure 87.
Figure 87 Email Configuration Menu
3. In this tab, enter all pertinent email information, including:
Enable Server Authentication: Enable if email server requires authentication. Enabling
Server Authenticating will enable the User Name and Password fields.
User Name: User name to use for server authentication.
Password: Password to use for server authentication.
SMTP Server: Address for SMTP server.
SMTP Port: Port for SMTP server.
Enable SSL: Enable Secure Sockets Layer (SSL) for out-going e-mail.
Sender Name: The sender name to use when an e-mail is sent out from the DVR.
Sender’s Address: The sender’s address to use when an e-mail is sent out from the DVR.
