98 Volara™ System, Model PVL1 User Manual (196286 REV C)
Specifications
SYSTEM COOL DOWN
CAUTION:
Caution—Failure to follow the system cool down guidelines below could
cause equipment damage.
WIRELESS COMMUNICATION
The Volara™ System, Model PVL1 features an optional Bluetooth®
interface to connect to a pulse oximeter or barcode reader to retrieve
patient information. The Volara™ System, Model PVL1 also features an
optional WiFi module to export system use data in both acute care and
home care environments.
Condition Cool Down Period
System operates continuously for
5 minutes, at CHFO pressure
setting of 65 cmH2O and above.
At least 20 minutes
Feature Dimension
Bluetooth® Specification (Optional Configuration)
Bluetooth® compliance Bluetooth® V4.0 (BT Classic)
Frequency 2.40 to 2.48 GHz
Transmit Power +8 dBm (max) + 0.5 dBm
Receive Sensitivity -90 dBm (typical)
Modulation Frequency shift keying
Frequency hopping spectrum
WiFi (Optional Configuration)
WLAN IEEE 802.11a, 802.11b, 802.11g, 802.11n
Frequency 2412 MHz - 2462 MHz
5180 MHz - 5240 MHz
5745 MHz - 5825 MHz
Transmit Power (+/- 2 dBm) 17.5 dBm for 802.11b DSSS
17.5 dBm for 802.11g/n OFDM
12 dBm for 802.11a/g/n OFDM
Receive Sensitivity (+/- 2
dBm)
1 Mbps - 95.5 dBm (<10% PER)
54 Mbps - 74.5 dBm (<10% PER)
MCS7 (20 MHz) - 71.5 dBm (<10% PER)
MCS7 (40MHz) - 68 dBm (<10% PER)
