76 Volara™ System, Model PVL1 User Manual (196286 REV C)
Accessories
Install the Control Unit on a Medical Rail or IV pole
CAUTION:
To help prevent equipment damage, obey these cautions and make sure
the mounting structure complies with these recommendations:
• Caution—Make sure the diameter of the pole for mounting the
pole clamp assembly is between 16 to 35 mm.
• Caution—Make sure the dimension of the medical rail is 25 by 10
mm.
• Caution—Make sure the safe working load of the mounting
structure (medical rail or IV pole system) is able to support the
weight of the control unit and pole clamp assembly. See “Product
Specifications” on page 96.
1. Find the preferred position to mount the pole clamp assembly.
2. Turn the knob on the pole clamp assembly clockwise to hold the tray
in position.
3. Put the control unit on the tray. Make sure the screw holes on the
bottom of the control unit are aligned with the screw holes on the
tray.
4. Attach the control unit to the tray with the supplied thumb screws.
196654__C_2019-Apr-29_Cleaned
