5-46 ●Code tables
Type Header Classification
Data
count
Data section
Recall Message number 20H 31H 4 0001 to 2000
Registration
Message number
21H
31H 4 0001 to 2000
Message name 32H 1 to 12 Message name: Max 12 digits
Print format
Line count, print format
uniformity
22H
31H 0 -
Line count/Line spacing 32H 2
Line count : 1 to 5
Line spacing: 0 to 2
Format setup change 33H 1 Format setup : 30H to 32H
Character size/
inter character space
23H
31H 3
Character size : 30H to 3CH
Inter character space : 00 to 28
Increased width 32H 1 1 to 9
Bar code 33H 1 30H to 47H
Readable code 34H 1 0 to 2
Prefix Code 35H 2 00 to 99
Free layout
Horizontal and Vertical
coordinate
24H
31H 8
Item number : 1 to 100
Horizontal (X) coordinate: 0 to 31998
Vertical (Y) coordinate : 0 to 29
Horizontal coordinate 32H 6
Item number : 1 to 100
Horizontal (X) coordinate : 0 to 31998
Vertical coordinate 33H 3
Item number : 1 to 100
Vertical (Y) coordinate : 0 to 29
Horizontal and Vertical
move
41H 10
Item number : 1 to 100
Horizontal (X) direction :
-31998 to +31998
Vertical (Y) direction : -29 to +29
Horizontal move 42H 7
Item number : 1 to 100
Horizontal (X) direction :
-31998 to +31998
Vertical move 43H 4
Item number : 1 to 100
Vertical (Y) direction : -29 to +29
Print
specifications
Character height
25H
31H 2 00 to 99
Ink drop use percentage 32H 2 01 to 16
High-speed printing 33H 1 0 to 2
Character width 34H 4 0000 to 3999
Character orientation 35H 1 0 to 3
Print start delay 36H 4 0000 to 9999
Print start delay (reverse) 37H 4 0000 to 9999
Product speed matching 38H 1 0 to 2
Pulse rate division Factor 39H 3 001 to 999
Repeat count 3DH 4 0000 to 9999
Repeat intervals 3EH 5 00000 to 99999
Target sensor timer 3FH 3 000 to 999
Target sensor filter 40H 1 1 to 2
Target sensor filter value 41H 4 0000 to 9999
Ink drop charge rule 42H 1 Charge rule : 31H to 33H
