5-26 ●Transmission Sequences
5.3.7-3 Example of count conditions transmission
(1) Example of reset
02H 1FH 2CH 3AH 31H 30H 30H 30H 30H 30H 03H
STXESC2, :100000ETX
Count Reset value 00000
block No.
5.3.8 User Pattern Character Transmission
5.3.8-1 Text
● When the number of communication bytes is set to "1" for communication
ESC2 Header 32H Classification
Character
code
Pattern data array
Character size
● When the number of communication bytes is set to "2" for communication environment setup purposes
ESC2 Header 32H Classification
High-order
byte
Low-order
byte
Pattern data array
Character size Character code
ESC2 Header 20H
Character
size
Character
code
Pattern data array
● When the number of communication bytes is set to "1" for communication environment setup purposes
● When the number of communication bytes is set to "2" for communication environment setup purposes.
ESC2 Header 20H
Character
size
High-order
byte
Low-order
byte
Pattern data array
Character code
Character size
0 : 5x5
1 : 5x8(5x7)
2 : 7x10
3 : 12x16
4 : 18x24
5 : 24x32
Header,
classification
[Transmission results]
Defines reset value 00000 for count block 1.
[Existing machine message] Existing machine message can also be used.
