●Transmission Sequences 5-19
5.3.6 Free Layout Transmission
5.3.6-1 Overview
● When Format setup is "Free layout", the selected print item can be moved individually.
● Free layout transmission shall be made independently. Free layout transmission can NOT be transmitted
with Print format or Print specification or Print description.
● If transmission is made to the item number(s) which does not exist, a communication error will occur.
● If transmission is made when the format setup is either "Individual" or "Overall", a communication error
will occur.
● If transmission is made to RX2-Basic machine, a communication error will occur.
5.3.6-2 Text
(1) Specify Horizontal/Vertical coordinate and move
● Specify the bottom-left coordinate and the print item will be moved.
● Horizontal and Vertical coordinate
ESC2 Header 24H
Classification
31H
Item
number
10000s
place
1000s place 100s place 10s place Unit place
(Contd.)
Item number
(1 to 100)
Horizontal (X) coordinate
(0 to 31998)
10s place Unit place
Vertical (Y) coordinate
(0 to 29)
● Horizontal coordinate
ESC2 Header 24H
Classification
32H
Item
number
10000s
place
1000s place 100s place 10s place Unit place
Item number
(1 to 100)
Horizontal (X) coordinate
(0 to 31998)
● Vertical coordinate
ESC2 Header 24H
Classification
33H
Item
number
10s place Unit place
Item number
(1 to 100)
Vertical (Y) coordinate
(0 to 29)
