5.8 Precautions
5.8.1 Notes on Product speed matching Feature Use
(1) If the product speed matching signal cannot be entered during printing, the printing state
continues to prevail so that communication may not be established (no response can be made).
If such a situation is encountered, perform procedure or below.
Enter the standby state and then initiate the communication.
Issue the print abort code "DC3". After the IJ printer returns an "ACK" response,
(2) Number of pulses necessary for a rotary encoder from print signal detection until the start of
printing.
Number of pulses necessary = Number of printing preparation pulses ( ) + Print start delay.
Number of printing preparation pulses = A / 1 scan time
Use an integer by rounding up the fractional portion.
Nozzle diameter Value of A
65μm5.5
1 scan time =
(Vertical dot count + character width setting) X Ink drop use percentage
Excitation frequency (kHz)
(ms)
5.8.2 Notes on Print Condition Transmission
(1) The number of digits for character height data is 2 by default. However, the preceding IJ printer
models GX and HX use 3 digits by default for print condition transmission (optional function). If the
new model of the IJ printer is used as a replacement for such a predecessor, open the following
screen from the communication environment setup screen and change the number of digits for
character height data to 3.
ESC Header 30H 100s place 10s place Units place
Character height (000 to 099)
● Character height (when the 3-digit data format is chosen)
Note: If the value is within the range from 100 to 999, an error occurs.
1
2
1
2
1
1
Data digts of the character height
When “Speed compensation” is enabled, print start is delayed for 30 scans.
