●Setting high-speed print (Optional on RX2-S) 9-6
No. Item Conditions
1 Print line
Number of lines of all columns is the same.
(Refer to Table in “ Type of high-speed print and number of
vertical dots used” for number of print lines available.)
2 Character size
Character size of all print items is the same.
(Refer to Table in “ Type of high-speed print and number of
vertical dots used” for character sizes available.)
3 Line spacing
Line spacing of all columns is the same. However, if Line spacing is
set to 3 or more, High-speed printing is NOT available.
4 Barcode NOT available.
5 Character orientation 0 or 1.
6 Ink drop use rate 1/1
7 Ink drop charge rule Standard (Single scan or interlaced)
HM mode NM mode Remarks
HM mode is equivalent to particle use
percentage of 1/1.
In the 2-line print setting, NM mode is
equivalent to ink drop use percentage
of 1/1.5.
If the line speed remains the same,
print width in the NM mode will widen
by 1.5 times with respect to HM mode.
Setting high-speed printing (Optional on RX2-S)
(1) Overview
● Three modes of HM, NM or QM can be selected.
By selecting the mode, high quality printing result can be ensured according to the line speed.
Necessary conditions to perform high-speed print
● When all necessary conditions from Nos. 1 to 7 are satisfied, high-speed print HM, NM or QM
mode can be selected.
1
2
2
To Next Page
