●Transmission Sequences 5-11
5.3.4-2 Message name
(1) message number specified
● A message name is automatically attached when print data is registered.
● Based on the message name displayed in the upper left hand corner of the screen, the last 4 digits are
replaced with the message number and used as the new message name.
(Example) Registering for No. 123
Contents displayed in upper left hand corner of the screen :“ABCDEFGHIJKL”
Message name after registration :“ABCDEFG 0123”
(2) Message number and message name specified
● The specified message name attached when print data is registered.
(3) Same message name is used for other message number
● If a message name is in use for other message number, new message name will be created by using
original message name as a base and replacing its 7th and 8th digits with AA~ZZ.
(Example) Message name [ABC] is already registered on No.1. Register on No.2 using identical
message name.
Message name of No.1: [ABC ]
Message name of No.2: [ABC AA ]
(4)Characters available for message name
● Characters used for setting the message name transmission are different from characters used in
manual input on registration screen.
Function
Alphameric character/
Symbols
Accent character/
Arabic character
Manual input Available Available
Message name transmission Available Unavailable
5.3.4-3 Supplement
● When transmitting print data together with the print contents, send the print contents last.
5.3.4-4 Example of print data registration transmission
(1) Example of registering by specifying message name
02H 1FH 21H 31H 30H 30H 31H 32H 1FH 21H 32H 41H 42H 43H 03H
STXESC2!10012ESC2!2ABCETX
Header, classification
Header, classification
Message name
[Transmission results]
Massage name "ABC" is assigned to current print data and is registered under message number 12.
Numbers/symbols (ASCII code): 20H to 5FH, 61H to 7AH
Print data message unmber
