●Set the user environment 6-2
Character orientation by “Change Character Orientation” and “Change mode” combination
Change Character
Orientation
Change mode
Character orientation
Reciprocative printing
signal : OFF
Reciprocative printing
signal : ON
Reverse direction printing
OFF = forward
0:ABC(→) 1:ABC(←)
3: (→) 2: (←)
OFF = reverse
1:ABC(←) 0:ABC(→)
2: (←) 3: (→)
Normal or inverted
OFF=normal
0:ABC(→) 2: (←)
3: (→) 1:ABC(←)
OFF=Inverted
2: (←) 0:ABC(→)
1:ABC(←) 3: (→)
Character orientation
0 or 3
OFF=normal and
forward
0:ABC(→) 3: (→)
1:ABC(←) 2: (←)
OFF=inverted
and reverse
3: (→) 0:ABC(→)
2: (←) 1:ABC(←)
ABC
ABC
ABC
ABC
ABC
ABC
ABC
ABC
ABC
ABC
ABC
ABC
6.1 Set the user environment
(1) Functions
●Sets the user environment values.
signal ON While print target detect sensor signal is ON.
OFF-ON transition When print target detect sensor signal is turned ON once
Repeat print sensor mode
●Sets the conditions that print the specified number of times at the specified interval.
●Disabled when Repeat count is “0”.
Change Character orientation (switching signal mode) (Optional on UX-B)
●Sets the forward and reverse character orientation method when performing reverse direction printing.
●The “Change mode” selection menu is different depending on the “Change Character Orientation” set value.
(Example) Assume that the Change Character Orientation is “Reverse direction printing”.
●If Change mode is “OFF = forward ”
When the reciprocative printing signal is OFF, prints in the forward direction and when the signal is
ON, prints in the reverse direction.
●If Change mode is “OFF = reverse”
When the reciprocative printing signal is OFF, prints in the reverse direction and when the signal is
ON, prints in the forward direction.
For more detail, see “(3)change character orientation (change mode) supplement”.
●When the Various print setup item “DIN print” is set to “Enable”, reciprocative print signal is not
received.
