●Set the print format (Fixed layout) 4-28
4.7.5 Print a bar code (UX-D,E only)
(1) Kinds of bar codes
●Different kinds of bar codes can be set for each print item.
Kinds of bar codes
Bar code Kinds of characters which can be input Remarks
Code 39
0 to 9 A to Z Space
+ - (minus) / . (period) $ %
ITF 0 to 99 Input of two-digit numbers
NW-7
0 to 9
+ - (minus) / . (period) : (colon) $
EAN-13 0 to 9
EAN-13 Add-On 5 0 to 9
EAN-8 0 to 9
UPC-A 0 to 9
UPC-E 0 to 9
Code 128
(code set B)
0 to 9 A to Z a to z Space
FNC1 Code B Code C Symbols
Input numeric of two-digit
numbers
Code 128
(code set C)
0 to 9 FNC1 Code B Code C
Data matrix
(DM)
0 to 9 A to Z a to z Space
FNC1 Symbols
QR code, Micro QR Same as above.
GS1 DataBar 0 to 9
Limited, Omnidirectional and
Stacked
●When a bar code of the same kind was set at adjacent print items, only the continuous series bar code is
assumed. However, fixed length bar codes such as EAN-13, EAN-8, UPC-A, UPC-E,
EAN-13 Add-On 5 and GS1 DataBar become independent bar codes.
●For multiple settings, provide a print item for which a bar code is not set between the print items with a
bar code set.
●Up to a maximum of 4 DM (Data Matrix), code 128, QR code, Micro QR and GS1 DataBar can be set
respectively.
QR code and Micro QR can be collectively set up to 4.
●Since the number of horizontal dots is uniquely determined for bar codes, an inter-character space cannot
be set.
●A bar code can be set even for print items with a calendar and count set. However, when calendar
substitution, zero suppression, or an invalid character is set, for the bar code setting, the relevant character
is deleted.
●Neither the calendar nor the count set can be set to the country code.
●When code set C of code 128 was set when the English alphabet is set for the count upper limit, the
relevant character is deleted.
●Since start and stop codes are automatically generated, input as print description is unnecessary.
●A barcode with the identification numbers can be set in 1 line or 2 lines setting.
When in 2 lines setting, the barcode with the identification numbers can only be set to either upper or
lower line.
If the barcode is set to the upper line, it cannot be set to the lower line or vice versa.
●For GS1 DataBar, neither the calendar nor the count can be set to 1st, 2nd and 3rd digit.
●Bar code cannot be set at character size 30 × 40 and 36 × 48 print items.
See the Technical Manual “9. APPENDIX” for details.
To Next Page
