ā—Print head 2-4
2.3 Print head
Print head cover lock thumbscrew
Nozzle orifice
Minus deflection electrode
Gutter
Plus deflection electrode
Charge electrode
Plus deflection electrode
Nozzle orifice
Gutter
Minus deflection electrode
Charge electrode
Print head cover lock thumbscrew
[UX-D,B]
[UX-E]
Air exhaust port
