Honda BF8D User Manual

Be careful not to spill fuel.
Spilled fuel or fuel vapor may
ignite. If any fuel is spilled,
make sure the area is dry
before storing or transporting
the outboard motor.
Do not smoke or allow flames
or sparks where fuel is
drained or stored.
102
Fuel Line Removal
TRANSPORTING10.
PULL
FUEL LINE CONNECTOR
FUEL LINE CONNECTOR
PPUUSSHH
Before transporting the outboard
motor, disconnect and remove the
fuel line in the following procedure.
While pressing the fuel line
connector clip, pull the fuel line
connector and disconnect it from
the outboard motor side joint.
While pulling the fuel line
connector cover, pull the fuel line
connector to disconnect the fuel
line connector from the fuel tank.
2.1.
11/09/05 18:12:49 32ZY0620_102

Honda BF8D Specifications

General

HP Rating	8 HP
Cooling System	Water cooled
Fuel Delivery	Carburetor
Ignition System	CDI
Starting System	Manual
Gear Ratio	2.33:1
Fuel Tank Capacity	12 L (external tank)
Engine Type	4-stroke
Full Throttle RPM Range	5, 000-6, 000 RPM
Shaft Length	381 mm (Short Shaft)
