Engine Oil Pressure and
Overheat Warning Systems
Engine Protection System
OPERATION
OIL PRESSURE
(GREEN)
OIL PRESSURE
(GREEN)
OVERHEAT
(RED)
BUZZER
(INDICATOR/WARNING LIGHT)
R Type
H Type
Oil Pressure Indicator
When the green light is lit, oil pressure is OK.
If oil pressure becomes low, the green light will go off,
and the engine protection system will limit engine
speed.
Remote control types are also equipped with a buzzer
that sounds when the green light goes off.
The buzzer sound stops below an engine speed of
1,400 rpm.
The engine speed does not increase if the throttle is
opened widely.
The engine speed increases gradually as soon as the
cause of the warning is removed.
Overheat Warning Indicator
If the engine overheats, the engine protection system
will limit engine speed (All types).
Remote control types are also equipped with a warning
light and a buzzer. Red light will come on and a buzzer
sounds if the engine overheats.
The engine speed does not increase if the throttle is
opened widely.
If the overheat condition continues for 20 seconds, the
engine is stopped; if the normal temperature is restored
within that time, the engine speed is gradually raised to
the normal cruising speed.
