Honda BF8D User Manual

Do not operate the outboard
motor without the engine cover.
Exposed moving parts can
cause injury.
Perform the following
pre-operation checks with the
engine stopped.
49
Removing/Installing Engine Cover
PRE-OPERATION CHECKS6.
ENGINE COVER LATCH
To remove, unlatch the engine
cover latch and remove the engine
cover.
To install, set the engine cover,
hook the front and rear latches,
and push down the rear engine
cover latch.
BF8D/BF10D/BF15D/BF20D is the
4-stroke, water cooled outboard
motor which uses unleaded regular
gasoline for fuel. It also requires the
engine oil. Check the following
before operating the outboard motor.
11/09/05 18:03:05 32ZY0620_049

Honda BF8D Specifications

General

HP Rating	8 HP
Cooling System	Water cooled
Fuel Delivery	Carburetor
Ignition System	CDI
Starting System	Manual
Gear Ratio	2.33:1
Fuel Tank Capacity	12 L (external tank)
Engine Type	4-stroke
Full Throttle RPM Range	5, 000-6, 000 RPM
Shaft Length	381 mm (Short Shaft)
