Honda BF8D User Manual

31
Power Tilt Switch
CONTROLS (T type)
CONTROL LEVER
(H type) (R type)
POWER TILT SWITCH
Press DN to tilt
the outboard
motor down.
Press UP to tilt
the outboard
motor up.
Press DN to tilt
the outboard
motor down.
PPrreessss UUPP ttoo ttiilltt
tthhee oouuttbbooaarrdd
mmoottoorr uupp..
POWER TILT SWITCH
Press the power tilt switch on the
control lever (R type) or tiller handle
(H type), and the outboard motor
installation angle (tilt angle) can be
adjusted only while stopping the boat.
Power tilt is a convenience for tilting
the outboard motor, shallow water
operation, and trailering only. It is
not designed to be used as a trim
function to adjust the trim angle of
the boat.
Excessive trim angle can result in
cavitation and racing of the propeller,
and tilting up the outboard motor
excessively can cause damage to the
impeller pump.
During shallow water operation,
beaching, launching, or mooring,
proceed at low speed with a small
throttle opening and tilt the outboard
motor up as necessary (see page ).98
11/09/05 17:59:33 32ZY0620_031

Honda BF8D Specifications

General

HP Rating	8 HP
Cooling System	Water cooled
Fuel Delivery	Carburetor
Ignition System	CDI
Starting System	Manual
Gear Ratio	2.33:1
Fuel Tank Capacity	12 L (external tank)
Engine Type	4-stroke
Full Throttle RPM Range	5, 000-6, 000 RPM
Shaft Length	381 mm (Short Shaft)
