CONTROLS
Transom Angle Adjusting Rod
(Manual tilt type)
(G and T type)
TRANSOM ANGLE
ADJUSTING ROD
TRANSOM ANGLE
ADJUSTING ROD
TRANSOM ANGLE
ADJUSTING ROD
Use the transom angle adjusting rod
to adjust the outboard motor angle
properly.
BF15D/BF20D
BF8D/BF10D
(SH type/LH type)
BF10D
(XH type/R type)
BF8D
(R type)
