39
Fuel Line Connector
CONTROLS
(FUEL TANK SIDE)
(OUTBOARD MOTOR SIDE)
FUEL LINE CONNECTOR
FUEL LINE CONNECTOR
The fuel line connector is used to
connect the fuel line between the
separate fuel tank and the outboard
motor.
11/09/05 18:00:52 32ZY0620_039

Table of Contents

Other manuals for Honda BF8D

Preview: Owner's Manual
Owner's Manual147 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda BF8D and is the answer not in the manual?

Honda BF8D Specifications

General IconGeneral
HP Rating8 HP
Cooling SystemWater cooled
Fuel DeliveryCarburetor
Ignition SystemCDI
Starting SystemManual
Gear Ratio2.33:1
Fuel Tank Capacity12 L (external tank)
Engine Type4-stroke
Full Throttle RPM Range5, 000-6, 000 RPM
Shaft Length381 mm (Short Shaft)
