Any other transport or storage
position may cause damage or
oil leakage.
136
Horizontal transport or storage:
Transport/Storage Position of the
Outboard Motor
Vertical transport or storage:
STORAGE
CASE PROTECTORPROTECTOR
Fill the battery with distilled water
to the upper level line. Never
overfill the battery.
Store the battery on a level surface
in a cool, dry, well ventilated place
out of direct sunlight.
Once a month, check the specific
gravity of the electrolyte and
recharge as required to prolong
battery life.
Transport and store the outboard
motor either vertically or horizontally,
as shown here. Store the outboard
motor in a well-ventilated area free
from direct sunlight and humidity.
Rest the outboard motor on the case
protector.
Attach the stern bracket to a stand.
Always rest the outboard motor on a
protector and be sure to protect it
from impact and damage.
3.
4.
5.
11/09/05 18:19:17 32ZY0620_136
