Honda BF8D User Manual

99
In an emergency;
In normal use;
Stopping the Engine
STOPPING THE ENGINE (H type)9.
THROTTLE GRIP
SLOW
SLOW
SHIFT LEVER
NEUTRAL
N(neutral)
PULL
EMERGENCY STOP
SWITCH CLIP
STOP
EMERGENCY STOP
SWITCH LANYARD
·····
·····
Disengage the emergency stop switch
clip from the engine stop switch by
pulling the emergency stop switch
lanyard.
It is a good idea to stop the engine
with the emergency stop switch
lanyard from time to time to be sure
that the emergency stop switch is
operating properly.
Turn the throttle grip to SLOW
position and move the shift lever
to N (neutral).
1.
11/09/05 18:12:19 32ZY0620_099

Honda BF8D Specifications

General

HP Rating	8 HP
Cooling System	Water cooled
Fuel Delivery	Carburetor
Ignition System	CDI
Starting System	Manual
Gear Ratio	2.33:1
Fuel Tank Capacity	12 L (external tank)
Engine Type	4-stroke
Full Throttle RPM Range	5, 000-6, 000 RPM
Shaft Length	381 mm (Short Shaft)
