Honda BF8D User Manual

Do not disassemble the gas
assisted damper assembly as it
is filled with the high pressure
gas.
Be sure to lower the tilt lever
and lock the outboard motor
before sailing. The outboard
motor could rise when sailing
in the reverse gear, resulting in
an accidental injury to the
passenger(s).
33
Tilt Lever
CONTROLS
(G type)
TILT LEVER
TTIILLTT
RRUUNN
((LLOOCCKK))
Use the tilt lever to temporarily raise
the outboard motor when the boat is
sailing in the shallows, or mooring or
anchoring in the shallows.
Raising the tilt lever unlocks the
outboard motor and the outboard
motor can be tilted. Lowering the tilt
lever locks the outboard motor.
11/09/05 17:59:54 32ZY0620_033

Honda BF8D Specifications

General

HP Rating	8 HP
Cooling System	Water cooled
Fuel Delivery	Carburetor
Ignition System	CDI
Starting System	Manual
Gear Ratio	2.33:1
Fuel Tank Capacity	12 L (external tank)
Engine Type	4-stroke
Full Throttle RPM Range	5, 000-6, 000 RPM
Shaft Length	381 mm (Short Shaft)
